AA-wiz

High-capacity battery for long distance.

Equipped with a large-capacity lithium-ion battery of approximately 4 kWh, it can travel long distances of up to 137 km on a single charge. This is enough capacity for a full day of riding.
Charged on the go.

Type 1 or Type 2 charging socket enables charging of the vehicle at home, and also at EV charging stations.
Disc brakes for stable performance.

The combination brake is designed for riders of all levels, and is designed to provide a well-balanced front and rear brake force.
In-wheel hub motor for powerful performance.

The compact in-wheel hub motor installed greatly reduce the number of drivetrain components and power loss.
Backing up is easy with the power of the motor.

Turning the throttle while pressing the switch on the right-hand steering wheel reverses the motor and backs the vehicle. Turning around in narrow alleys and parking spaces can be done easily while sitting in the seat.
Large LCD display.

The large full-color LCD display comes with simple graphical display of speed, remaining battery capacity, mileage, clock, and various indicators.

Specifications below are development target values.
They are subject to change without notice.

	AA-wiz α	AA-wiz β
Classification	L1e/ 50cc equivalent	L3e/ 125cc equivalent
Overall LWH	1,945 x 685 x 1,120mm
Seat height	700mm
Weight	143kg
Power	0.3kW	–
Wheel Size	F/W 13inch
Brake	Disk CBS
Battery capacity	3.85kWh
Distance per charge	137km ※
Charging time	Around 3 hours full charge, 2 hours 75%

* Distance when running at a constant 30km/h.
Actual distance may vary depending on weight load and road conditions.

Coming soon…

183L Rear box

The front and rear of the vehicle has a flat cargo bed. Depending on the cargo to be carried, a front basket or rear box can be attached.

external dimensionsWidth 585 x Depth 533 x Height 643mm
apertureWidth 520 x Height 491mm
Charging cable

Two types are available: single-phase 200 V and single-phase 100 V (with grounding). Please select according to the operating environment. The body side is J1772 connector.
※The photograph shows 200V type.

Ability to travel longer distance
with a big battery.
AA-wiz is your business partner whenever you go.

L1e/L3e

Distance up to 137km
per charge.

When running at a constant 30km speed per hour.
